Signature™ ONE Surgical Planning

Software and Guides

Signature ONE | Main Product Image

Signature™ ONE Surgical Planning

Software and Guides

Based on each patient’s unique anatomy, integrated with proprietary algorithms and known anatomical landmarks, Signature ONE offers a tailored approach to shoulder arthroplasty.

It provides a 3D image-based approach to preoperative visualisation, surgical planning and patient specific guide creation.

Signature One | Promo Card Image
Shoulder to Shoulder Interactive Overview

Features
Signature ONE Planning

Using a CT scan, an initial surgical plan is provided, incorporating preferences and patient landmarks. Adjustments can be easily made based on a quick review. The software includes Zimmer Biomet's key shoulder arthroplasty systems - Comprehensive™ Total, Reverse, and Augmented options, as well as the Trabecular Metal Reverse Plus®(TMR+) System and Alliance™ Glenoid (Pure Planning only).

Adjustable attributes, based on presenting indications and surgical goals, include:

  • Backside contact and 3D measurement tools

  • Lateralisation reference points to assist in preserving glenoid bone

  • Quick changes from non-augmented to augmented components for maximum bone preservation

  • Ability to visualise inferior glenosphere offset to improve ROM

  • Central screw length visualisation

Signature ONE Guides

Once the surgical plan is approved by the submitting surgeon, guide creation begins and is provided for in-surgical use with several key supporting components:

  • Signature ONE Glenoid Guide for accurate pin placement

  • Patient glenoid bone model for visual confirmation throughout the procedure

  • Depth control arm to assist accurate glenoid depth reaming

The Signature ONE Guides are placed on the glenoid to guide initial pin placement without adding extra steps to the surgical procedure. A secondary superior pin is inserted for accurately controlled ream depth, which is crucial for achieving maximum bone preservation of the glenoid.

Benefits
Confidence

Better understand patient anatomy with high-quality 3D reconstruction and the ability to reproduce that plan to the patient.

Simplicity

Easy to use guides and software interface.

Convenience

On-line access with any computer or iPad® along with a surgical technique that fits intuitively within existing techniques.
